SG285

GOBLIN FIREBALL HAVOK

SKU: SG285 bar code: 8935254812753
Availability: Out of stock
Purchase and Earn 489 Points
$489.00
GOBLIN FIREBALL HAVOK
SG285
goblin-280havok-sg285-on-black
goblin-fireball-havok-sg285-lat-sx
goblin-fireball-havok-sg285-hcorner-sx
goblin-fireball-havok-sg285-front
goblin-fireball-havok-sg285-lat-dx
goblin-fireball-havok-sg285-corner-sx
GOBLIN FIREBALL HAVOK
  • Havok new matt graphic scheme registered design 003738210-0001/0004

Risorsa 1
Blade Size 280
icona-peso
Weight (no battery/fuel) 735g
battery-icon_1
Power supply 6S 1000/1250 mAh

GOBLIN FIREBALL HAVOK EDITION

• Havok new matte graphic scheme

Registered design 003738210-0001/0004

GENERAL SPECIFICATIONS

• Includes 60A SAB ESC

• Includes 4 servos

• Motor competition HE015

• Red aluminium blade grip arms

• Red aluminium bell crank

• Red aluminium servo support

• Yellow Havok lighter FG canopy

• Yellow Havok carbon-reinforced boom

Kit upgrades
Total price
GOBLIN FIREBALL HAVOK $489.00
Total $489.00
Out of stock

Helicopter Main Data

280-data
Configuration 6S Setup
Available P/N SG280-SG281-SG285-SG289
Main rotor diameter 625mm
Main blade length 280mm
Tail rotor diameter 139mm
Tail blade length 50mm
Main shaft diameter 5mm
Tail shaft diameter 3mm
Weight 735g (ex. Battery)

Helicopters Secondary Data

Cyclic Servos Micro size 23 mm
Tail Servo Micro size 23 mm
Typical speed controller 50 - 60A
Maximum motor size Includes
Motor KV Includes
Battery compartment 73x37x42 mm
Battery capacity 6S 1000/1250 mAh
Available ratios 1,0

Spare Parts

Nylon Nut M2.5
HC200-S Nylon Nut M2.5
$5.00
Nylon Nut M3
HC206-S Nylon Nut M3
$4.00
Shims 5x7x0,1
HC450-S Shims 5x7x0,1
$4.00
Tail Hub
H0771-S Tail Hub
$8.80
Plastic Ball 4mm
H0779-S Plastic Ball 4mm
$5.00
Tail side plate
H0780-S Tail side plate
$7.80
Tail Pin
H0781-S Tail Pin
$5.00
Tail Pulley 19T
H0782-19-S Tail Pulley 19T
$9.80
Main Shaft
H0784-S Main Shaft
$12.80
Main Blade Grip
H0785-S Main Blade Grip
$9.80
Swashplate
H0788-S Swashplate
$19.00
Spindle
H0792-S Spindle
$5.80
Servos Linkage
H0796-S Servos Linkage
$4.80
Bell Cranl Lever
H0797-S Bell Cranl Lever
$9.80
Landing Gear
H0799-S Landing Gear
$9.50
Fireball Frame SX
H0832-S Fireball Frame SX
$11.50
Fireball Frame DX
H0833-S Fireball Frame DX
$11.50
Main Plate
H0838-S Main Plate
$15.50
Feeder
H0839-S Feeder
$7.80
Tail Shaft
H0842-S Tail Shaft
$6.50
Wire positions
H0858-S Wire positions
$5.80
Strap 205x16
HA044-S Strap 205x16
$4.80
Fireball Sticker
HA064-S Fireball Sticker
$5.50
Micro Servo Horn
HA065-S Micro Servo Horn
$7.80
Nylon Nut M2
HC492-S Nylon Nut M2
$6.50
Oring 70 shore
HC501-S Oring 70 shore
$4.00
Set Screw M2.5x4
HC499-S Set Screw M2.5x4
$5.00
Set Screw M3x4
HC500-S Set Screw M3x4
$5.00
Set Screw M2x10
HC498-S Set Screw M2x10
$5.00
Tail Belt Guide
H0872-S Tail Belt Guide
$14.50

Upgrades

SAB Tool Kit
HM054 SAB Tool Kit
$49.00
SAB Tool Case
HM053 SAB Tool Case
$19.00
SAB Key Chain
HM061 SAB Key Chain
$4.00
Oring 90 shore
HC502-S Oring 90 shore
$6.00
Aluminum Pulley
H0901-S Aluminum Pulley
$19.00
Pulley 18T
H0782-18-S Pulley 18T
$18.50
Tail Blade Grip
H0772-S Tail Blade Grip
$23.50
Back Servo Support
H0915-S Back Servo Support
$12.50
Swashplate Leveler
H0928-S Swashplate Leveler
$18.50
Letter Sticker
HA070-S Letter Sticker
$7.00
Goblin Fireball 280 Manual Release 1.0L

Goblin Fireball 280 Manual Release 1.0L

Fireball Havok SG285 Sheet

Fireball Havok SG285 Sheet
