SG514

GOBLIN 500 SPORT LINE

SKU: SG514 bar code: 8935254811954
Availability: Out of stock
Purchase and Earn 489 Points
$489.00
GOBLIN 500 SPORT LINE
Banner Sport.jpg
GOBLIN 500 SPORT LINE
Risorsa 1
Blade Size 500
icona-peso
Weight (no battery/fuel) 1880g
battery-icon_1
Power supply 6S 3300/4500 mAh

Specifications:

The Goblin 500 Sport line has been developed to provide the best performance for the best price.

  • Stylish fiberglass canopy.  RRP $69

  • New carbon tail boom manufactured using an innovative lower cost process pushing the RRP down to RRP $56

  • G10 mainframe delivers performance on a budget. RRP $19.5. Compatible with the standard carbon frame to allow simple upgrading.

  • No blades included, giving you more freedom to choose your style and control your budge

  • Ability to use medium and full-size servos

  • The structural plates are now made of a plastic material Zytel70G33L. This change ensures a reduction of 48 grams in weight.

  • Main gear CNC H0423 (aluminum/delrin) in the basic kit

  • New Swashplate with high quality spherical bearing


  • Kit Includes:

  • 18T motor pulley (other pulley sizes available)

  • 2 battery trays

The following motor pulleys are available:

  • 16T Pulley (P/N 0215-16-S) Ratio 10.33:1

  • 17T Pulley (P/N H0215-17-S) Ratio 9.72:1

  • 18T Pulley (P/N H0215-18-S) Ratio 9.18:1

  • 19T Pulley (P/N H0215-19-S) Ratio 8.7:1

  • 20T Pulley (P/N H0215-20-S) Ratio 8.26:1

  • 21T Pulley (P/N H0215-21-S) Ratio 7.87:1

  • 22T Pulley (P/N H0215-22-S) Ratio 7.51:1

  • 23T Pulley (P/N H0215-23-S) Ratio 7.19:1

  • 24T Pulley (P/N H0215-24-S) Ratio 6.91:1

    All these motor pulleys are for a 6 mm motor shaft. Each pulley includes an adapter for 5 mm motor shafts.

  • HPS Head System

  • Dampened tail system for increased vibration tolerance

  • Cnc main gear

  • Main plate and servo support in technopolymer Zytel

  • Landing gear

  • All servo sizes compartible

  • Battery tray

  • Break away Nylon screws

Kit upgrades
Total price
GOBLIN 500 SPORT LINE $489.00
Total $489.00
Out of stock
Discontinued

Helicopter Main Data

500-data
Configuration 6S Setup
Available P/N SG507-SG508-SG509-SG510-SG512-SG514
Main rotor diameter 1136mm
Main blade length 500mm
Tail rotor diameter 230mm
Tail blade length 80mm
Main shaft diameter 10mm
Tail shaft diameter 6mm
Weight 1880g (ex. Battery)

Helicopters Secondary Data

Cyclic Servos Mini size 36mm
Tail Servo Standard size 40mm
Typical speed controller 100 A
Maximum motor size 52 mm diameter x 56 mm height
Motor KV 1100-1350KV
Battery compartment 50x54x180 mm
Battery capacity 6S 3300/4500 mAh
Available ratios From 6.91 to 10.33
