SG583

Goblin RAW 580

SKU: SG583
Availability: In stock
Purchase and Earn 738 Points
$738.00
Goblin RAW 580
Risorsa 1
Blade Size 580
icona-peso
Weight (no battery/fuel) 2710gr
battery-icon_1
Power supply 12s 2600-3300 | 6s 5000-5500

The new RAW 580 use the same module from Kraken 580.

-Incredible strong Power train enclosed in aluminum case,

-Ultra light 7075 aluminum alloy highly adjustable rotor head with super simple Tail group,

-Aluminum Boom 30 mm

-Easy maintenance

-Main blades up to 600mm.

TECHNICAL SPECITICATIONS

-AIRFRAME weight: 1740gr ( with S580 blades, no battery, no electronics )

-Main blade length: 550mm to 600mm

-Tail blade length: 95 to 105 mm

-Main rotor diameter: 1290 mm (with 580 mm blades included)

-Tail rotor diameter: 260 mm (with 95 mm tail blades included)

-Cyclic Servos: mini cyclic servo (torque over 8 Kg-cm). Kit includes servo mounts for mini-servos. Full size servo mounts available separately.

-Tail Servo: standard size 40mm.

-Main Rotor ratio : 11.5 to 8.6 :1 ( 22T included: 9.4:1)

-Tail Rotor ratio : 5.3-4.9:1 ( 23T included: 4.9:1 )

-Typical motor : 4025 series, 6S 1000-1200 Kv, 12S 500-600 Kv. Minimum motor shaft length is 26mm (We recommend using a 6mm diameter motor shaft)

-Typical speed controller: 6S 120-140 A, 12S 100-130A

-Battery size: 6S 5000/5800 mAh, 12S 2600/3200 mAh.

Kit upgrades
Total price
Goblin RAW 580 $738.00
Total $738.00

Helicopter Main Data

RAW580 spec
Configuration 580
Available P/N SG583
Main rotor diameter 1290mm with 580mm Main Blades
Main blade length 580mm to 600mm
Tail rotor diameter 260mm with 95mm Tail Blades
Tail blade length 95mm to 105mm
Main shaft diameter 10mm
Tail shaft diameter 5mm
Weight 1740gr ( with blades, no battery, no electronics )

Helicopters Secondary Data

Cyclic Servos Mini Size 36mm
Tail Servo Standard size 40mm
Typical speed controller 6S 120A 12S 130A
Maximum motor size 52 mm diameter x 58 mm height
Motor KV 6S 1000-1400KV 12s 500-700KV
Battery compartment 6S 50x60x200 mm 12S 50x45x280 mm
Battery capacity 6S 5000/5500 mAh 12S 2600/3300 mAh
Available ratios From 8.5 to 12.9

Spare Parts

Nylon Nut M2.5
HC200-S Nylon Nut M2.5
$5.50
Nylon Nut M3
HC206-S Nylon Nut M3
$4.50
Strap 20x250mm
HA041-S Strap 20x250mm
$7.00
Canopy Base
H1101-S Canopy Base
$24.00
Reference Pin
H1048-S Reference Pin
$5.00
Battery Tray
H1102-S Battery Tray
$21.00
Wire Cover
H1107-S Wire Cover
$9.00
Grease LDS
HA075-S Grease LDS
$11.00
Grease NBU
HA076-S Grease NBU
$11.00
Antenna Support
H1134-S Antenna Support
$7.00
Aluminum Main Blades Grip Black Matte
H1368-S Aluminum Main Blades Grip Black Matte
$48.00
Tail Belt 1722-6mm
HC592-S Tail Belt 1722-6mm
$27.00
Washer Set
HC594-S Washer Set
$16.00
Steel Main Shaft
H1299-S Steel Main Shaft
$18.00
Belt Tensioner
H1278-S Belt Tensioner
$18.00
CF Tail Fin
H1196-S CF Tail Fin
$19.00
Tensioner Idle
H1066-S Tensioner Idle
$15.00
Tail Orings
HC598-S Tail Orings
$7.00
RAW 580 Canopy RAW 580 Canopy
H1438-S RAW 580 Canopy
$99.00
Aluminum Top Case Aluminum Top Case
H1503-S Aluminum Top Case
$55.00
Canopy Front Block
H1439-S Canopy Front Block
$10.00
FBL Rubber Pin
HC573-S FBL Rubber Pin
$8.00
FBL/RX SUPPORT
H1625-S FBL/RX SUPPORT
$23.00
